DOW UF
- Module Specifications
Module Properties SFX-2660 SFX-2680 SFX-2860 SFX-2880
SI US SI US SI US SI US Length - L 1860 mm 73.2" 2360 mm 92.9" 1860 mm 73.2" 2360 mm 92.9" Length - L1 1500 mm 59.1" 2000 mm 78.7" 1500 mm 59.1" 2000 mm 78.7" Length - L2 1610 mm 63.4" 2110 mm 83.1" 1630 mm 64.2" 2130 mm 83.9” Length - L3 1710 mm 67.3" 2210 mm 87.0" 1820 mm 71.7" 2320 mm 91.3” Diameter - D 165 mm 6.5" 165 mm 6.5" 225 mm 8.9" 225 mm 8.9" Width – W1 125 mm 4.9" 125 mm 4.9" 180 mm 7.1" 180 mm 7.1" Width – W2 250 mm 9.8" 250 mm 9.8" 342 mm 13.5" 342 mm 13.5" Surface Area 33 m2 355 ft2 44 m2 474 ft2 51 m2 549 ft2 77 m2 829 ft2 Volume per Module 16 L 4.2 gal 20 L 5.3 gal 35 L 9.3 gal 39 L 10.3 gal Weight (water filled) 41 kg 90 lbs 53 kg 117 lbs 83 kg 183 lbs 100 kg 220 lbs Shipping Weight (w/o packaging) 25 kg 55 lbs 33 kg 73 lbs 48 kg 106 lbs 61 kg 135 lbs Fibers/ Module 5,760 5,760 9,000 10,000 Housing UPVC UPVC UPVC UPVC
